UHMWPE HDPE PP Engineering Plastic Sheets

Multi-Material Engineering Plastic Made-to-Order

High-Density Engineering Plastic Sheets — UHMWPE / HDPE / PP

Name: High-Density Engineering Plastic Sheets — UHMWPE / HDPE / PP
Brand: Jiasheng Plastics
SKU: JS-ENG-MULTI-001
Availability: InStock
Rating: 4.9 (42 reviews)

Jiasheng Plastics is your one-stop industrial partner for premium engineering plastic sheets. We specialize in high-performance UHMWPE, HDPE, and Polypropylene (PP) boards, offering a comprehensive range of thicknesses and sizes for global industrial applications.

Material: UHMWPE / HDPE / PP
Thickness: 1 – 200 mm
Sheet Size: Up to 1500×6000 mm
Color: Natural, Black, Colored
Tolerance: ±2% – ±5%
Surface Finish: Smooth / Textured / Sanded
Capacity: 1000+ tons / month

Request a Free Quote Chat on WhatsApp

Quality Certified Direct Factory ISO / FDA / SGS Fast Global Delivery

Product Description

As a leading manufacturer in the engineering plastics industry, Dezhou Jiasheng Rubber and Plastic Products Co., Ltd. provides a diverse portfolio of high-density plastic sheets including UHMWPE (Ultra-High Molecular Weight Polyethylene), HDPE (High-Density Polyethylene), and PP (Polypropylene). Each material is selected and processed to meet specific industrial demands. UHMWPE is the ultimate choice for extreme wear resistance and low-friction sliding applications, while HDPE offers an excellent balance of chemical resistance and impact strength for tanks and structural components. PP stands out for its superior heat resistance and chemical stability in aggressive environments, making this trio the backbone of modern industrial fabrication.

Our engineering plastic sheets are manufactured using state-of-the-art extrusion and compression molding technologies. This allows us to offer thicknesses ranging from thin 1mm foils to massive 200mm heavy-duty slabs. At our facility in Dezhou, we maintain strict quality control protocols, ensuring that every sheet delivered meets the rigorous standards required for mechanical engineering, chemical processing, and food production. Whether you need the self-lubricating properties of PE-1000 or the rigid structural integrity of industrial-grade PP, Jiasheng Plastics has the material science and manufacturing capacity to deliver the perfect solution for your project.

We pride ourselves on being more than just a material supplier; we are a comprehensive solution provider. Beyond supplying raw sheets, our in-house CNC machining center is equipped with high-precision routers and milling machines capable of transforming these plastics into finished industrial components. From wear strips and chain guides to chemical tank liners and precision-machined gears, we handle the entire process from resin to final part. Our commitment to using 100% virgin materials ensures that our products maintain their mechanical properties and chemical resistance even in the most demanding operational conditions, providing long-term value and reduced maintenance costs for our clients worldwide.

Technical Specifications

Property	Unit	UHMWPE (PE1000)	HDPE (PE300)	PP (Polypropylene)
Density	g/cm³	0.93 – 0.95	0.95 – 0.97	0.90 – 0.92
Molecular Weight	Million g/mol	3.5 – 9.2	0.3 – 0.5	N/A
Tensile Strength	MPa	25 – 40	22 – 28	30 – 35
Flexural Modulus	MPa	800 – 1000	1000 – 1200	1300 – 1500
Hardness	Shore D	62 – 66	64 – 68	70 – 75
Coeff. of Friction	—	0.10 – 0.15	0.20 – 0.25	0.30 – 0.35
Impact Strength	kJ/m²	No Break	12 – 18	6 – 10
Service Temp.	°C	-200 to +80	-50 to +80	0 to +100
Water Absorption	%	< 0.01	< 0.01	< 0.01
Dielectric Strength	kV/mm	20 – 30	20 – 25	30 – 40

Typical values for natural grade materials. Specialized additives (UV, FR, Anti-static) will alter these properties. Contact us for specific data sheets.

Key Features & Advantages

Multi-Material Versatility

Access UHMWPE, HDPE, and PP from a single factory, ensuring material compatibility and streamlined procurement.

Exceptional Chemical Resistance

All three materials are highly resistant to acids, alkalis, and organic solvents, perfect for chemical storage and processing.

Superior Size Range

We produce sheets up to 6000mm in length and 200mm in thickness, catering to large-scale industrial projects.

In-House CNC Fabrication

Professional nesting and machining services reduce waste and provide ready-to-install components directly from our factory.

FDA & Food Grade

Virgin resins ensure compliance with food safety standards for use in processing, packaging, and cutting boards.

Direct Factory Pricing

By eliminating intermediaries, we provide competitive FOB/CIF pricing without compromising on material quality.

Typical Applications

Industrial Wear Liners

UHMWPE liners for chutes, hoppers, and truck beds to prevent sticking and reduce wear.

Chemical Processing Tanks

HDPE and PP sheets for fabricating acid-resistant tanks, plating baths, and fume hoods.

Food Processing Equipment

Food-grade PE boards for cutting surfaces, star wheels, and conveyor components.

Marine & Dock Fenders

UV-stabilized UHMWPE panels for dock protection and bridge pylon fenders.

Water Treatment Facilities

HDPE components for clarifiers, filtration systems, and wastewater management tanks.

Agricultural Silos & Bunkers

High-slickness liners for grain silos and fertilizer storage to ensure smooth material flow.

Sizes & Customization

At Jiasheng Plastics, we understand that industrial projects often require non-standard dimensions. We offer a vast range of customizable options for our UHMWPE, HDPE, and PP sheets. Our standard stock sizes include 1220x2440mm and 1500x3000mm, but our advanced production lines can produce custom lengths up to 6000mm. Thicknesses are available from 1mm up to 200mm, with tight tolerances maintained throughout the production process to ensure ease of installation and machining.

Our CNC Machining Service is at the heart of our customization capability. We utilize multi-axis CNC routers to provide precision cutting, drilling, and profiling. Whether you need a simple rectangular cut-to-size service or complex three-dimensional components like star wheels, gears, or manifold blocks, we can manufacture them directly from your CAD files. We also offer surface texturing, edge beveling, and plastic joining services to provide a truly turnkey solution for your engineering needs.

Frequently Asked Questions

What are the primary differences between UHMWPE, HDPE, and PP sheets?

UHMWPE offers the highest wear resistance and lowest friction, ideal for heavy-duty industrial sliding. HDPE is a versatile, cost-effective material with good chemical resistance and impact strength, often used for tanks and cutting boards. PP (Polypropylene) has the highest heat resistance and stiffness among the three, making it perfect for chemical plating tanks and heat-intensive industrial applications.

Can you manufacture sheets in custom colors?

Yes, we provide natural, black, and a wide variety of colors including blue, green, yellow, and red. Custom color matching is available for large-volume orders (typically 1000kg+ MOQ per color). We use high-quality pigments that are UV-resistant and color-fast.

What is the maximum sheet size you can produce?

For our multi-material engineering sheets, we can produce sizes up to 1500×6000mm. Standard sizes like 1220×2440mm and 1000×2000mm are kept in stock for immediate shipment. Custom widths up to 2000mm are also available for specific material grades.

Are these materials food-safe and FDA compliant?

Yes, our natural UHMWPE, HDPE, and PP sheets are manufactured from 100% virgin resins that meet FDA and EU food contact standards. They are non-toxic, odorless, and resistant to bacterial growth. We provide material certifications and SGS test reports upon request.

Do you offer CNC machining for these engineering plastics?

Absolutely. Jiasheng Plastics operates a state-of-the-art CNC machining center. we can cut, drill, mill, and route your sheets into complex components based on your CAD drawings or technical specifications. This ensures high precision and reduces waste on your end.

What is the typical lead time for an international order?

Stock items ship within 3-5 days from our Dezhou factory. Custom production orders usually take 10-15 working days. Shipping via sea from Qingdao or Tianjin port typically takes 20-40 days depending on the destination. Air freight is available for urgent small-batch orders.
