UHMW-PE FDA Grade Self-Lubricating

UHMW-PE Chain Guide Rail — Conveyor Wear Strips & Profiles

Name: UHMW-PE Chain Guide Rail
Brand: Jiasheng Plastics
SKU: JS-UHMWPE-CG-001
Availability: InStock
Rating: 4.8 (28 reviews)

🛡️

🛡️ Patented Design

Selected chain guide profiles (ETA, CTS, T-Double, T-Triple) are protected by 4 granted Chinese national design patents (ZL 2019 3 0354736.2 · 0354737.7 · 0404445.X · 0404443.0) — designed by our GM Feng Jian, valid through 2029.

View Patent Certificates →

Ultra-high molecular weight polyethylene (PE1000) guide rails and wear strips designed for high-speed conveyor systems, packaging machinery, and food-grade environments.

Material: Virgin UHMW-PE (PE1000)
Profiles: T, L, U, Flat, Custom CNC
Standard Length: 2 m / 3 m / 6 m (Max)
Density: 0.94 – 0.97 g/cm³
Friction Coeff.: 0.10 – 0.15 (Static)
Color: Green, White, Natural, Black
Compliance: FDA / SGS / REACH
Price: Quote on request (MOQ from 1 piece)

Request a Free Quote Chat on WhatsApp

Trade Assurance 3-Year Gold Supplier SGS / FDA / RoHS verified / FDA / SGS Fast Global Shipping

Product Description

Jiasheng Plastics specializes in the precision manufacturing of UHMW-PE Chain Guide Rails (PE1000), essential components for modern conveyor systems in the food, beverage, packaging, and automotive industries. Our guide rails are engineered from virgin ultra-high molecular weight polyethylene, a material renowned for its combination of extreme wear resistance and a very low coefficient of friction. By replacing metal or lower-grade plastic guides with our UHMW-PE profiles, manufacturers can significantly reduce energy consumption, minimize chain noise, and extend the service life of expensive conveyor chains.

One of the standout features of our chain guides is their self-lubricating property. The molecular structure of UHMW-PE acts as a dry lubricant, allowing metal or plastic chains to glide effortlessly without the need for external oils or greases. This is particularly critical in food processing and pharmaceutical packaging, where oil contamination must be avoided at all costs. Our white and natural-colored guides are fully FDA-compliant, ensuring they meet the strictest hygiene standards for direct contact with food and beverages.

We provide a comprehensive range of profile types, including the widely-used T-profiles, U-profiles, and L-profiles, as well as specialized curves and corner tracks. Utilizing advanced CNC machining technology, we can produce custom cross-sections and complex profiles according to your specific equipment designs. Whether you need standard wear strips for a simple bottle conveyor or high-performance MoS2-filled guides for heavy-duty automotive assembly lines, Jiasheng Plastics delivers the precision and durability your operations demand.

Technical Specifications

Property	Test Method	Value	Unit
Density	ISO 1183	0.94 – 0.97	g/cm³
Molecular Weight (Viscosity-Avg.)	ASTM D4020	≥ 5,000,000	g/mol
Tensile Strength at Yield	ISO 527	≥ 20	MPa
Coefficient of Friction (Static)	ASTM D1894	0.10 – 0.15	—
Coefficient of Friction (Dynamic)	ASTM D1894	0.12 – 0.18	—
Shore Hardness	ISO 868	63 – 66	Shore D
Impact Strength (Charpy Notched)	ISO 179	No break	kJ/m²
Service Temperature (Continuous)	—	−200 to +80	°C
Melting Point	ISO 3146	133 – 135	°C
Water Absorption	ISO 62	< 0.01	%
Linear Thermal Expansion	ASTM D696	1.8 – 2.2 × 10⁻⁴	m/m/°C
Food Grade Compliance	FDA 21CFR	Compliant	—

Technical values are for 100% virgin PE1000. Custom filled grades (MoS2, Oil, Ceramic) may have different values. Mill Test Reports (MTR) provided.

Key Features & Advantages

Low Friction Coefficient

Dynamic friction as low as 0.12. Reduces motor load and energy consumption while preventing chain stuttering.

FDA Food-Grade Approved

Non-toxic and odorless material safe for direct food contact. Ideal for bottling, canning, and meat processing.

Self-Lubricating / No Oil

Dry-running performance eliminates the need for external lubrication. Maintains a clean production environment.

Quiet Operation

Significant noise reduction compared to metal guides. Creates a safer and more pleasant working environment.

Custom CNC Profiles

Precision machining to your drawings. T, L, U, and complex 3D profiles for any conveyor brand or model.

Long Service Life 5+ Years

Exceptional wear resistance ensures long maintenance intervals and reduced total cost of ownership.

Typical Applications

Bottle & Can Conveyors

Chain guides and neck guides for high-speed brewery, soft drink, and canning lines.

Packaging Machinery

Wear strips and sliding guides for cartoning, shrink-wrapping, and labeling equipment.

Food Processing

FDA-compliant guides for meat, poultry, and bakery conveyors requiring frequent washdowns.

Automotive Assembly

Heavy-duty chain tracks for chassis and engine assembly lines with high-load requirements.

Sorting Systems

Low-friction guides for parcel and luggage sorting conveyors in airports and logistics centers.

Brewery Conveyors

Water and chemical-resistant guides for keg and crate handling in humid environments.

Available Sizes & Customization

Standard Profile Options

T-Profiles: Standard widths 30, 40, 50, 60 mm
U-Profiles: For various chain sizes (ISO 06B, 08B, 10B, 12B, etc.)
L-Profiles and Z-Profiles for side guiding
Flat wear strips: 3–25 mm thickness, up to 300 mm width
Standard lengths: 2000 mm and 3000 mm

Customization Services

Custom CNC-machined cross-sections to drawing
MoS2-filled (Grey/Black) for lower friction
Oil-filled (Green) for high-speed lubrication
Pre-drilled and counterbored mounting holes
Snap-on designs for C-channel mounting
Max length up to 6000 mm for seamless runs

Frequently Asked Questions

What are the main benefits of using UHMW-PE for chain guides?

UHMW-PE is the ideal material for chain guides due to its exceptionally low coefficient of friction and high wear resistance. It significantly reduces the power required to drive the conveyor system while protecting the metal chains from premature wear. Additionally, its self-lubricating nature eliminates the need for messy oils, and its high impact strength ensures it can handle high-speed operations without cracking.

Are your chain guides FDA-compliant for food and beverage contact?

Yes, our virgin white and natural-colored UHMW-PE chain guides are fully FDA-compliant and safe for direct food contact. They are non-toxic, odorless, and do not absorb moisture or harbor bacteria. This makes them perfect for use in bottling lines, canning facilities, and food processing plants where hygiene and chemical resistance to cleaning agents are critical.

Can you manufacture custom profiles based on our technical drawings?

Absolutely. While we offer standard T-profiles, U-profiles, and L-profiles, the majority of our production is custom CNC-machined. Our multi-axis machining centers can accurately reproduce complex cross-sections, beveled entries, and specific mounting slots from your CAD or PDF drawings. We can produce continuous lengths up to 6 meters to minimize joints in your conveyor run.

What is the service life of an UHMW-PE chain guide rail?

Under typical industrial conditions, our PE1000 chain guides offer a service life of 5 to 8 years. The exact longevity depends on the chain speed, load, and environmental temperature. For high-load or high-speed applications, we also offer MoS2-filled (Molybdenum Disulfide) or oil-filled UHMW-PE grades which further reduce friction and heat buildup, extending the rail's life.

Which colors are available for conveyor wear strips?

Green is the industry-standard color for UHMW-PE conveyor components, but we also regularly produce guides in white (FDA grade), natural, and black (UV-stabilized). Custom colors like blue or yellow are also available for large orders to match your brand or to differentiate between different production lines in your facility.

What is the typical lead time for custom-machined chain guides?

Standard profiles in stock colors can usually be shipped within 5-7 working days. Custom CNC-machined profiles typically require 10-15 working days depending on the complexity and quantity. We provide efficient shipping via sea, air, or express (DHL/FedEx) to ensure your production line maintenance or project deadline is met.
